rfid card reader security turnstile gate sliding gate turnstile
FORWARD SMART turnstiles are all design,research,develop and
produced by our own,we have appearance designer,more than 10-20
years experience structure engineers,workers,full kinds of
production equipment include laser cutting machine,slot shaping
machine,plate shears,bending machine,and so on.
| Specification |
| Power consumption | 100W |
| Housing Size | 1200*280*1000mm |
| Housing material | 1.5--2mm, 304# stainless steel, corosion resistant |
| Drive motor | DC brushless motor |
| Channel width | ≤1200mm |
| Pass speed | 30 persons or bike/min. |
| Panel open/close time | 1.5s(adjustable) |
| IP protection | IP44 |
| Input singal optional | DC12V/dry/contact/RS485/RS232/Remote) |
| railing-off against power off | Yes |
| Working enviroment temperature | minors 30°C to 70 °C |
| Working environments | indoor,outdoor |
| Relative humidity | ≤95% coagulation free |
| MCBF | 2,500,000 cycle |
Competitive Advantage:
1.1.5mm thickness 304 stainless steel
2. RFID card (IC/ID), Barcode, fingerprint, control accepted
3. CE and ISO 9001-2008 certified
4. OEM and ODM are welcome.
FAQ Regarding turnstile:
1.What`s the difference between manual type turnstile and automatic
type turnstile?
A. Manual turnstile, it hasn't electric control device, Automatic
type, it can compatible with access control system.
B.Manual turnstile, it is single direction, For automatic type, it is
bi-direction,
2.What`s the difference between full auto turnstile and semi-auto
turnstile?
A.Full-auto type, it is motorized. For semi-auto, it is solenoid.
B. Full-auto type, after card reading, the arm will rotate 10-15
degree. Passengers push it to pass.
Semi-auto type, after card reading, passengers push the arm to pass.
C. Full Automatic turnstile, The Pole automatically falls down when electricity is
cut down, and the arm will be automatically when the power on.
Semi-auto turnstile, when power failure, the middle arm will drop automatically, and
when power on again, it needs people to lift it.
3.What`s the MOQ?
The MOQ of our tripod turnstile is 1 pc/pair
4.Whether the size and shape of turnstile can be changed?
OEM is available, we can produce the non-standard turnstile if customer offer
drawing or if customer need us to design a new turnstile.
