Heavy duty tripod turnstile with fingerprint card reader for
entrance and exit
Features:
1 with fault detection and alarm function for illegal come.
2 time of reflection test is adjustable after read the card.
3 have read card and memory function.the user can set up access to
read cards many times or pass though access one.
4 with automatic reset function, passager read valid card, pass
though within the stipulated time, the system will automatically
cancel the access permissions for users
5 has a unified, standard external electrical interface ,can be
connected many kinds of reading cards.can realize remote control
and manage by operating the computer.
Tripod Turnstile Parameters:
Protection | When the external force exceeds a set value (eg 40 kg) bezel can be
rotated in order to protect the chip from loss, followed by
automatic reset |
consist | Chip,housing,control panel and power | Turnstile direction | Single direction/bi-direction |
configuration | Frame / stainless steel / cold plate spray | Chip drive way | Direct current motor |
Anti-reverse | With anti-reverse function,guarantee one person one card | temperature | -40°C--60°C |
power | AC220V±10% 50HZ±4% | Humidity | 5%-95% |
output | AC24V,DC12V,DC5V | speed | ≥25 persons/minute |
consumption | Static: single 20W; dynamic: single 60W | noise | ≤50db |
Work environment | Indoor,outdoor | Passage width | 550-570mm |
Interface parameter | RS232 singal one pcs,reader 2pcs,fire alarm function one pcs | Examine interface | 2pcs |
lifespan | Ten years(no consumption) | Protection scale | IP42 |
demenstion | 1200*280*1040mm |
Tripod turnstile net weight | 65kg(not include control parts) |
Application:
Mainly used for walkways and sale and ticket vending
management.such as government,companies,liberary,residential
areas,official building ,factories,bus-station,scenic spot,leisure
and entertainment club etc.
Our biggest advantage is that we accept most kinds of
customization.Nowadays almost all customers prefer special and
unique products,we know it is quite difficult to do with various of
solutions,but we are glad of it,the only reason is that customers
demand it,and we have full ability to cater them.such as Beijing
Capital International Airport just chose our turnstiles to serve
passengers that come from all the world.
