Automatic Pedestrian Stainless Steel Rfid Security Access Control
System
FORWARD SMART turnstiles are all design,research,develop and
produced by our own,we have appearance designer,more than 10-20
years experience structure engineers,workers,full kinds of
production equipment include laser cutting machine,slot shaping
machine,plate shears,bending machine,and so on.
Product Specifications:
| Product Name | Wing Flap Barrier Turnstile | Working Temperature | -25°C-+60°C |
| Housing Size | 1260*280*1000mm | Relative Humidity | ≤90% non-condensing |
| Gross Weight | 75kgs | Max Channel Width | ≤1200m |
| Net Weight | 70kgs | Power Supply Voltage | AC 220V±10V, 50-60Hz |
| Wing Width | ≤285mm | Drive Motor | DC Motor 200W 24V |
| Drive Current | ≤10mA | Working Mode | One Directional or Bi-Directional Optional |
| Housing Material | 304 grade stainless steel | Working Environment | Indoor or Outdoor |
| Control Type | IC/ID/Barcode/Fingerprint control | Model Number | WQ-SL/L/02 |
| Machine Center | Imported Germanic Technological Motor | Passing Speed | 30-40 person/min |
| Communication Interface | RS485 | Communication Distance | ≤1200mm |
| Motor Rotating Speed | 1600 RPM | | |
Description:
1 With a self-test and alarm function, user-friendly maintenance
and use
2 Through the main control on the half-built small-press plate,
programmable devices running status
3 Mechanical structure, sensor features dual anti-trap, in the
process of telescopic boom reset when you meet resistance,
automatically stop or in the default time motor stopped working
4 Sound, light alarm functions, including unlawful entry, trailing
alarm
5 Erosion control features, in the absence of gate opening signal
is received, the arm automatically locked
6 Telescopic synchronization
7 With automatic reset function, gate opening, after a specified
period of time does not pass; the system will automatically cancel
the user's current access permissions
8 Power off automatically after the channel open, power-on
self-closing
9 Connecting with a variety of reading devices which can be linked
to the work of receiving the signal relay switch
10 May be one-way or two-way control personnel access to
11 Managing computer directly through the remote control and
management
12 Counting function can be expanded
13 Chassis lengthened, telescopic boom material selection
Applications:
Wing turnstiles are mainly used in parks, subway, customers,
airport, bus station, office building, scenic spot, community,
attractions, and exhibition hall doors, residential, Construction
Sites, Industrial Plants, Marquee Golf Tournaments, State Fairs,
Special Sporting Events and Festivals!
