Outdoor rfid reader tripod turnstile access control anti-crash
Competitive Advantage:
1.1.5mm thickness 304 stainless steel
2. RFID card (IC/ID), Barcode, fingerprint and coin control
accepted
3. CE and ISO 9001-2008 certified
4. OEM and ODM are welcome.
Specifications:
Name | Tripod Turnstile | Model | WQH-TS14 |
Housing Size | 1400x280x1000mm | Passing speed | 30 person/min |
Passage width | 520mm | Working Voltage | AC220V±10V, 50HZ |
Housing Material | 304 grade stainless steel optional | Motor voltage | 220V |
IP grade | IP42 | Logic voltage | 24v |
Control type | IC/ID/Barcode control ,QR code, Ticket, face recognition,
fingerprint accepted | Transmission | Sine Linkage |
Noise | ≤60dB | Frequency | 50Hz |
Motor | Brushless motor | Working temperature | -10°C--+60°C |
Working mode | one directional or
bi-directional optional | Operating humidity | 5%~95% |
Communication Interface | RS485/RS232; TCP/IP | Operation life | ≥3 million times |
Description:
1. Bridge-type turnstile, without side covered glass plate
2. Stainless steel 304#
3.Brushless motor
4.Encoder inside,more accurate
5.noise:≤60dB
6.working circumstance
:temperature-10degree~60degree;humidity:5%~95%
7.support input way: Two-side card reading, paper ticket,
fingerprint, coins.
8. Led light direction guide and LED display
9. The Pole automatically falls down when electricity is cut down,
and the arm will be automatically when the power on.
First class R&D
Our company has very strong R&D team to develope new product
including software and hardware
Over 30 staff with tremendous experience and knowledge
All control panel such as parking management system, fast speed
barrier gate, flap gate, road blocker , RFID reader , Parking
guidance system etc are developed by our R&D team.
Efficiency work rate with new product and customize request
Strictly QC
Quality is the life of our company!
1)10 QC with 3-5years working experience
2) Quality is controlled from source and by every stuff works in
Wanqiao Hong Company, below is the QC procedure:
Purchase, Machining Shop, Sheet metal workshop, Painting workshop;
→QC; →Warehouse; →Aging test; →Assembly plant.
