Rfid card reader access control automatic tripod turnstile gate
Product Description
1, gate machine communication: TCP / IP, free signal line;
2, with fault self-test and alarm prompts, user-friendly to
maintain and use;
3, power automatically open the door, call self-test and restore
the lock state;
4, can set a variety of job types, two-way need to swipe, one-way
swipe card to the other free passage;
5, with automatic reset function;
6, with 485 remote switch function to meet the special needs of
users and fire safety requirements.
7, anti-punching function, when not receiving the gate signal, the
telescopic arm automatically locked;
8, Infrared / mechanical double anti-folder function, sound and
light alarm function;
9, the standard electrical interface, with a variety of card reader
equipment connected to receive relay switch signal work;
10, pass counting function;
11, memory function can be set freely;
12, can realize intelligent access control, intelligent attendance,
smart charging and other functions;
Applications:
Tripod turnstiles are mainly used in parks, subway, customers,
airport, bus station, office building, scenic spot, community,
attractions, and exhibition hall doors, residential, Construction
Sites, Industrial Plants, Marquee Golf Tournaments, State Fairs,
Special Sporting Events and Festivals!
| Specification |
| Power consumption | 100W |
| Housing Size | 1200*280*1000mm |
| Housing material | 1.5--2mm, 304# stainless steel, corosion resistant |
| Drive motor | DC brushless motor |
| Channel width | ≤1200mm |
| Pass speed | 30 persons or bike/min. |
| Panel open/close time | 1.5s(adjustable) |
| IP protection | IP44 |
| Input singal optional | DC12V/dry/contact/RS485/RS232/Remote) |
| railing-off against power off | Yes |
| Working enviroment temperature | minors 30°C to 70 °C |
| Working environments | indoor,outdoor |
| Relative humidity | ≤95% coagulation free |
| MCBF | 2,500,000 cycle |
FAQ Regarding turnstile:
1.What`s the difference between manual type turnstile and automatic
type turnstile?
A. Manual turnstile, it hasn't electric control device, Automatic
type, it can compatible with access control system.
B.Manual turnstile, it is single direction, For automatic type, it is
bi-direction,
2.What`s the difference between full auto turnstile and semi-auto
turnstile?
A.Full-auto type, it is motorized. For semi-auto, it is solenoid.
B. Full-auto type, after card reading, the arm will rotate 10-15
degree. Passengers push it to pass.
Semi-auto type, after card reading, passengers push the arm to pass.
C. Full Automatic turnstile, The Pole automatically falls down when electricity is
cut down, and the arm will be automatically when the power on.
Semi-auto turnstile, when power failure, the middle arm will drop automatically, and
when power on again, it needs people to lift it.
3.What`s the MOQ?
The MOQ of our tripod turnstile is 1 pc/pair
4.Whether the size and shape of turnstile can be changed?
OEM is available, we can produce the non-standard turnstile if customer offer
drawing or if customer need us to design a new turnstile.
