Model No | WanqiaoTS06 |
Cabinet material | 304 Staintless Steel |
Passage width | 550mm-600mm |
Pass speed | over 30 persons/min |
Power supply | 220~240 V(AC) |
Max power consumption | 60w |
Frequency | 50~60 mhz |
Pass speed | 30people/min |
Mechanism | Electromagnetic |
IP Protection | IP54 |
Working temperature | -35~+70 °C |
Working environments | indoor /outdoor |
Swing Turnstile Features :
1. Housing Material: bright 304# stainless steel, 1.5mm thick,
laser-cut smooth sides.
2. Built-in card-swiping face plate, 5mm thick, seamless
combination with housing.
3. Single/dual directional card-swiping function, with swiping
indicators and direction indicator.
4. Acrylic barrier gate, 10mm thick, night light is optional for
swing turnstile.
5. Support Fire Signal open, release deadlock status after outage
for free passage and for preventing panics.
It can be set for constant open or close with remote control
function.
6. With sound and light alarms for below abnormal situations:
Anti-tailing, anti-intruding, anti-reverse- passage.
7. Swing turnstile is with 4 pairs of hidden infrared fence.
8. The Turnstile is very easy to integrate the readers and writers
of ID, IC, RFID, Fingerprint, barcode, card collectors, cellphone
2D codes, facial recognition instrument, etc.
Features of Swing Barrier:
● Crafted stainless steel and acrylic with excellent appearance,
make it a high-end decoration as well as access cotrol system.
● Automatically controlled by the built-in board with industrial
grade high speed CPU, react quickly.
● Anti-pinch function, the panel would stop closing temporarily
when meet with certain resistance.
● Can be set as normally open or normally closed, and direction can
be set as bi-direction or single direction.
● Compatible credentials: IC / ID cards, bar codes, fingerprints,
etc.
● Auto open and provide a free way when power off, in case of fire
accident.
● Counter function (optional), provide valuable data for business.
● The side panels could be illuminated to enhance aesthetics, and
provide visual notification of credential status.
● Wide aisle passage, available for the disabled and old.
