1. Full automatic
2. RS485 Communication
3. DC Brushless motor
4. Competitive factory price
Full Height Turnstile Features:
1. Auto-reposition function: After card read, passengers don‘t pass
within regulated time period, turnstile will be locked
automatically
2. Direction can be set as single-direction or bi-direction
3. When power off, arm will be locked automatically.
4. Self-lock function: arm will be locked automatically after
passenger passing.
5. 4 arms are always closed with each turning 90 degrees
6. Can be used with variety of card readers: IC / ID card readers,
bar codes, fingerprints, etc. (Access controller needed).
7. RS485 interfaces can connect turnstile with computer directly
8. Stable running with little noise.
9.Working mode and opening time is adjustable
10. .peration Place:Subway Station, Hoverport,Tourism
Sports,Exhibition, Swimming Hall,Residence Area,Enterprise’s
Full Height Turnstile Parameters:
| Product name | full height turnstile |
| Model | WQH-TR03 |
| Housing Material | 202or304 grade stainless steel |
| Housing Size | 1630x1500x2300mm |
| Passing speed | 30 person/min |
| Working Voltage | AC220V±10V,50HZ |
| Net Weight | 200kg |
| Gross Weight | 215kg |
| Motor voltage | 220V |
| Rated Power | 80W |
| Control type | IC/ID/Barcode control |
| accepted Transmission | Sine Linkage |
| Boom length | ≤700mm |
| Frequency | 50~60Hz |
| Logic voltage | 24v |
| Working mode | one directional or bi-directional optional |
| Operating humidity | ≤90% non-condensing |
| Communication Interface | RS485/RS232 |
| Operation life | ≥5 million times |
| Voltage | AC 220V±10%, 50±10%HZ |
| Frequency | 50/60Hz |
| Control circuit | 24V DC |
| Arm | 580 mm |
| Passage Width | ≤600mm |
| Temperature | -20℃~65℃ |
| Humidity | Less thank 95%,no condensation |
| Speed | 30 - 40/min |
Advantages of Our Services:
1) Products:
*All of the productions are acquired CE and ISO 9001-2008
Certificate, Lifespan over 5 years guarantee under properly working
circumstances.
*Totally Excellent EXW Price with great after-sale service.
2) Quality Control:
All of the productions must go throught a full professional test
procedure before the shipment:
>A. Powder coating Test
> B. 48Hrs High temperature aging Test
> C. 48Hrs Low temperature (-50°
>D, Humidity aging Test.
The Low-Returning Rate: <1%.
3) Warranty: Provide 1 year of warranty, our specialist team do best to help
you on the journey.
4) Various payment Terms: T/T, Western Union etc.
5) Quick & Safe Delivery: Been specializing in this field for years, we have established
many reliable partners, Best freight and good service for the
shipping, 24Hrs tracking make sure all the goods arrived on time &
safely
