RFID Flap Anti Collision Swing Barrier Turnstile

    Buy cheap RFID Flap Anti Collision Swing Barrier Turnstile from wholesalers

    Buy cheap RFID Flap Anti Collision Swing Barrier Turnstile from wholesalers
    • Buy cheap RFID Flap Anti Collision Swing Barrier Turnstile from wholesalers

    RFID Flap Anti Collision Swing Barrier Turnstile

    Ask Lasest Price
    Brand Name : FORWARD SMART
    Model Number : TB06
    Certification : ISO9001:2015
    Price : USD500-800pieces
    Payment Terms : T/T
    Supply Ability : 1000pieces per month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    RFID Flap Anti Collision Swing Barrier Turnstile


    Rfid flap barrier anti-collision swing barrier electrical turnstile barrier


    Product Description


    Swing barrier gate Specification:


    Technical parameters
    Housing material304 stainless steel
    DimensionsL1400*W180*H990mm
    Arm length500mm(Standard),≤750mm
    Weight80kg
    Power of motorDC24V
    VoltageAC220V±10%
    Frequency50Hz
    MCBF5 million cycles
    Transit speed35 persons/min
    Operating environmentIndoor/outdoor (Shelter)
    Operating temperature-30°C ~ 60°C
    Operating humidity≤95% no condensation

    Key Features:


    > Full opening clearance:

    Flap wing retracted into the housing does not take up any space to achieve maximum passage clearance. This allowed user to pass through with small and medium size luggage


    > Safety function.

    By default flap wing will autoreverse if IR sensor detected obstacle within the flap wing area. This avoid flap wing to accidentally hit onto to user. There is green light lining effect along the edge of the flap wing to ensure flap wing is easily visible.

    > Anti-tailgating.

    As a second option, flap barrier can be set to pause the flap wing if IR sensor detected obstacle nearby wing area. Flap will resume closing once the obstacle is removed. This is to make it very difficult for following user to tail gate the first user.

    > Time-out protection.

    Flap will auto close if there is no pedestrian pass through after the delay time elapsed. This revent unauthorized user from sneaking into the building.

    > Bi-directional.

    Pedestrian flow directions can be single or double directions.


    > Alarm function.

    Top red strobe light will blink when IR sensor detected unauthorized person in the lane.


    > Robust design.

    Flap barrier offers the most efficient opening and closing. Limited movement trajectory offlap wing reduces the possibility of damage by vandalism.

    > Emergence recovery.

    During power failure, flaps will automatically open. Flap wing will automatically close back after power supply resumed. External dry contact from fire alarm can trigger all flaps to open for fast evacuation. Flap wing will automatically close back once alarm signal is disabled.

    > LED indicator function.

    LED indicator light is available at both directions to indicate if the lane is available to use (green arrow) or lane is closed formaintenance (red cross).

    > Easy integration.

    There is a big opening 14 x 18 cm on top cover slanted surface. Reader holder bracket is available for installing RFID reader underneath arylic cover plate. LCD screen, bar code scanner orfingerprint reader can be installed on top of arylic.
